2023 VULCAN S-Special
2023 VULCAN S - Special for Sale at Ultimate Kawasaki Gold Coast in Nerang, QLD | Specifications and Review Information
SPORTBIKE PERFORMANCE MEETS CRUISER STYLE
Unlike any other cruiser, the Vulcan S is designed to transport riders into a sporty realm in edgy style. Blending an aggressive ride with a vintage styling and a powerful 649 cc engine, this bike kicks any experience into high gear. Whether you’re commuting to work or enjoying a day trip, the Vulcan S adds confidence-inspiring performance to every ride.
FEATURING:
- 649 cc PARALLEL-TWIN ENGINE
- SPORTBIKE-DERIVED CHASSIS AND SUSPENSION
- FIND YOUR FIT WITH ERGO-FIT TECHNOLOGY
PEARL SAND KHAKI / EBONY - EN650DPFAW
LIQUID COOLED PARALLEL TWIN ENGINE
Liquid-cooled, DOHC, 8-valve 649 cm3 Parallel Twin, fuel injected. Delivers smooth performance in the low and medium rpm ranges. The engine was tuned for rider-friendly power characteristics that will inspire confidence in all riders. The Vulcan S offers smooth starts, smooth acceleration, and a satisfying pull when accelerating. The Vulcan S is fitted with the Kawasaki neutral finder; when stationary in first gear, just shift up and it will easily find neutral.
TYRES AND BRAKES
Wheel sizes (18-inch for the front, 17-inch for the rear) are closer to those found on a sport bike than a typical cruiser model (which often have much larger front wheels). The slightly larger front wheel contributes to the Vulcan S's natural, light handling. The Vulcan S is equipped with front and rear ABS disc brakes. The 300mm front is gripped and 250mm rear brake rotors are gripped by a twin-piston caliper at the front and a single piston caliper for ample stopping power.
CUSTOM FIT & ADJUSTABILITY
Footrest position adjustable with three positions available: STD, 25 mm forward, 25 mm back. (Alternate shift linkage rods, sold separately, are necessary when changing the position from standard.) Optional accessories available at an additional cost: Reduced Reach and Extended Reach accessory seats are available to customise your fit.
LOW COMFORTABLE SEAT
Features a low 705mm seat height. The seat design with thick, 62mm padding offers a wide surface and excellent hip support, ensuring ample comfort for city riding and short tours. The seat bracket is rubber-mounted, reducing vibration transferred through the seat. Optional accessories available at an additional cost: Reduced Reach and Extended Reach accessory seats are available to customise your fit.
D-SHAPED SWING ARM
The swingarm's D-shaped cross-section gives it a pipe-like design that matches the frame, and contributes to the high-quality appearance.
OFFSET REAR SHOCK
Offset laydown rear single-shock supension is distinctive syling element, contributing the trend setting design. Pre-load adjustment is via an easy access 5-way cam wheel.
LONG RANGE
Tear drop-style fuel tank adds a cruiser-style touch. With its 14 litre tank capacity and the Parallel Twin engine's good fuel economy, the long range offered by the Vulcan S means riders can go longer between fill-ups-convenient in town, and reassuring when out on a daytrip.
INSTRUMENTATION
Analogue-style tachometer and multi-function LCD screen use blue LED backlights for excellent visibility at night. Include a fuel gauge, digital speedometer, clock, odometer, dual trip meters, remaining range, average/instant fuel consumption and the Economical Riding Indicator.
STYLING ELEMENTS
Curved, flowing style blended with a powerful, long-and-low stance and modern elements creates a unique, eye-catching design. Inverted triangle headlamp contributes to the Vulcan S's fresh, unique design. A position lamp is built into the upper portion of the headlamp unit.
REAR FENDER
Tail fender shaped to hug the rear wheel as closely as possible, creating a compact cruiser-style design. The design was made possible in part by the offset laydown rear shock.
FRAME
Elegant pipe perimeter frame is a key component of the Vulcan S's identity. The bike's bodywork accentuates the frame. The design of the frame, rear suspension and swingarm create an integrated line running from the front of the bike to the rear hub. A pipe frame of high-tensile steel gives the bike a lightweight appearance.
MUFFLER
Attractive bend of the exhaust pipes and an under-engine muffler arrangement contribute to the Vulcan S's attractive styling.
Maximum Power | 35.0 kW {48 PS} / 6,600 rpm |
Maximum Torque | 53.0 Nm {5.4 kgfm} / 5,600 rpm |
Engine | 4-stroke Parallel Twin |
Displacement | 649 cc |
Bore x Stroke | 83.0 x 60.0 mm |
Compression Ratio | 10.8:1 |
Valve System | DOHC, 8 valves |
Fuel System | Fuel injection: ø38 mm x 2 with dual throttle valves |
Ignition | Digital |
Starting | Electric |
Cooling | Liquid-cooled |
Lubrication | Forced lubrication, semi-dry sump |
Transmission | 6-speed, return |
Primary Reduction Ratio | 2.095 (88/42) |
Gear Ratio: 1st | 2.438 (39/16) |
Gear Ratio: 2nd | 1.714 (36/21) |
Gear Ratio: 3rd | 1.333 (32/24) |
Gear Ratio: 4th | 1.111 (30/27) |
Gear Ratio: 5th | 0.966 (28/29) |
Gear Ratio: 6th | 0.852 (23/27) |
Final Reduction Ratio | 3.067 (46/15) |
Clutch | Wet multi-disc, manual |
Final Drive | Chain |
Frame | Perimeter, high-tensile steel |
Front Suspension | ø41 mm telescopic fork |
Rear Suspension | Offset laydown single-shock, linkage-equipped, with adjustable spring preload |
Front Wheel Travel | 130 mm |
Rear Wheel Travel | 80 mm |
Rake | 31.0° |
Trail | 120 mm |
Steering Angle (L/R) | 35° / 35° |
Front Tyre | 120/70R18M/C 59H |
Rear Tyre | 160/60R17M/C 69H |
Front Brake/s | ø300 mm disc |
Front Caliper/s | Dual-piston |
Rear Brake | ø250 mm disc |
Rear Caliper | Single-piston |
Dimensions (LxWxH) | 2,310 x 880 x 1,100 mm |
Wheelbase | 1,575 mm |
Road Clearance | 130 mm |
Seat Height | 705 mm |
Curb Mass | 226 kg |
Fuel Capacity | 14 litres |
Model Code | EN650DPFAW |
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner's Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
